AXIS REVERBARATORY FURNACE are used primarily for melting copper and its alloys such as bronze and brass, and other metals like aluminum, lead ad zinc. The furnace is supplied with refractory lining tilting arrangement, and conventional/compact combustion system.

The furnace is constructed from reinforced mild steel plates of substantial thickness and is supported on a heavy fabricated stand suitable for gear/motor tilting, hydraulic with power pack tilting system all are user selection. The gear drive consists of two cylinders at both ends get tilted with power pack and directional valve.
The furnace can be fitted with Axis’s fuel efficient conventional/compact combustion system for the fuels like HSD,LDO, LSHS, FUEL OIL PG, NG, LNG, CNG, and LPG. The burner I designed fire tangentially from the shell to the pouring axis. Waste gases pass through the chimney on top, which can be serve as a charging door. This ultimately serves in other way to preheat the solid scrap. Furnace Extraction unit can be offered as an optional.

Optional Accessories:

  1. Oil Serve Tank
  2. Out Flow Heater
  3. Semi Rotary Pump For Oil Tank
  4. Fume Extraction Unit
Highlights
  • Rugged Construction
  • Efficient Heat Transfer
  • Easy to operate & maintain
  • Fitted with Axis Highly acclaimed combustion system
  • Excellent fuel economy
  • Axis quality built into every machine
furnace Model
Charge (KG) For Iron
Dimensions(mm)
brass aluminium A B C D E
RV-2 90 30 4200 1450 2000 1300 2800
RV-5 225 75 4500 1550 2200 1400 2950
RV-10 450 150 4800 1625 2500 1550 3050
RV-20 900 300 5000 2125 2650 1730 3200
RVA-33 - 500 5500 2200 2900 1850 3400
